MA-4.600은 4 x 4 라우팅 매트릭스를 가진 콤팩트 한 4 채널 디지털 앰프입니다. 중소규모 프로젝트에 이상적이며 용도가 다양하며 가격 대비 효율이 뛰어납니다. 미디어 컨트롤을 쉽게 운용할 수 있으며 USB-C소켓을 통해 Fohhn Audio Soft로 쉽게 구성할 수 있습니다.
Electronic features
-
amplifier technology : Class D
-
amplifier outputs : 4
-
DSP routing (matrix) : 4 × 4
-
frequency response : 20 Hz – 20 kHz
-
signal/noise ratio : > 103 dB/A
-
THD+N : 0,15% (1 kHz, 8 ohms, 3 dB below clipping)
-
dynamic range : > 120 dB
-
password protection : yes
-
auto power save : adjustable from 1 s to 12 h, or never active
-
protective circuit : over voltage protection, over current protection, over temperature protection, short-circuit protection, DC protection, power on delay, soft start and inrush current limit
-
power supply : 100 – 240 V AC 50/60 Hz, universal power supply with Power Factor Correction (PFC)
-
power consumption : maximum 700 W, idle state 35 W, Auto Power Save 2 W, standby 2 W
-
heat dissipation : max. 120 W, 410 BTU/h, 104 kcal/h
-
temperature range : 0 – 40°C
-
cooling : temperature-controlled fan
-
output power : 4 × 600 W / 4 ohms / 100 V / 70 V, 4 × 300 W / 8 ohms (1 kHz, THD+N <1 %)
-
minimum impedance : 4 ohms
-
input channels : 4
